CX-AG07

GPS Antenna

  • Frequency Range: 1575.42 MHz (GPS L1)
  • Gain: 28 dB (Active)
  • Voltage: 3–5V DC
  • Connector Type: SMA Male / Customizable
  • Cable Length: 3m (custom options available)
  • Impedance: 50 Ω
  • VSWR: ≤ 2.0
  • Polarization: Right-Hand Circular Polarization (RHCP)
  • Housing Material: ABS, black, weatherproof
  • Mounting Type: Magnetic / Adhesive base
  • Operating Temperature: -40°C to +85°C


Descritption CX-AG07

The CX-AG07 is an active GPS patch antenna designed for reliable satellite tracking in compact devices. It features a low-profile housing, integrated LNA, and rugged design suited for outdoor or automotive use. Good gain and low noise make it ideal for applications like vehicle navigation, asset tracking, and IoT systems.
