CX-MH02

UAV-FPW Antenna Drone Transmission

Frequency Range: 5.8 GHz
Polarization: Circular (RHCP/LHCP)
Gain: 8 dBi
VSWR: ≤ 1.5
Impedance: 50 Ω
Connector Type: SMA Male (or customizable)
Cable Length: 15–30 cm (optional)
Radiation Pattern: Directional
Material: ABS enclosure with internal copper radiating elements
Dimensions: 80 × 80 × 20 mm (each panel)
Operating Temperature: -40°C to +85°C
Application: FPV drone transmission, UAV telemetry, wireless communication modules, and long-range video systems.

Enquire Now

Download Specification

Descritption CX-MH02

The UAV-FPW Antenna Drone Transmission CX-MH02 is a high-performance dual-panel FPV (First Person View) antenna system designed for long-range drone communication. With advanced circular polarization and low-loss transmission lines, it ensures stable, interference-free video and control links — ideal for professional UAV applications and FPV racing systems requiring reliable, high-speed signal transfer.
