CX-AP45F

UAV-FPW Antenna Drone Transmission

  • Frequency Range: 5.8 GHz
  • Gain: 14–16 dBi
  • Polarization: Linear / Circular (optional)
  • VSWR: ≤ 1.5
  • Impedance: 50 Ω
  • Connector Type: SMA / RP-SMA (customizable)
  • Cable Type: RG316 / RG141 low-loss cable
  • Beamwidth: 35° Horizontal / 30° Vertical
  • Operating Temperature: -40°C to +85°C
  • Material: ABS radome with weather-resistant coating
  • Mount Type: Panel or UAV integrated mount
  • Application: Drone transmission, FPV systems, wireless telemetry, and ground control stations.


Descritption CX-AP45F

The UAV-FPW Antenna Drone Transmission CX-AP45F is a high-performance, flat-panel antenna designed for long-range and stable signal transmission in UAV and FPV systems. It offers excellent directional gain, low loss, and superior noise resistance, making it ideal for professional drone communication, telemetry, and HD video transmission applications.
