CX-AP46

UAV-FPW Antenna Drone Transmission

Frequency Range: 5.8 GHz
Gain: 16 dBi
Polarization: Circular (RHCP/LHCP optional)
VSWR: ≤ 1.5
Impedance: 50 Ω
Connector Type: SMA Male / RP-SMA optional
Cable Type: RG316 low-loss coaxial cable
Beamwidth: 35° Horizontal / 30° Vertical
Material: High-strength ABS with UV and weather resistance
Mount Type: Panel or bracket mount
Dimensions: Compact and lightweight for drone integration
Operating Temperature: -40°C to +85°C
Applications: Long-range FPV systems, UAV telemetry, wireless data transmission, and control systems.

Enquire Now

Download Specification

Descritption CX-AP46

The UAV-FPW Antenna Drone Transmission CX-AP46 is a precision-engineered flat panel antenna designed for UAVs and FPV systems requiring extended transmission range and superior signal clarity. Its directional radiation pattern and high gain ensure reliable long-distance communication, making it suitable for drone video, telemetry, and data transmission applications.
